Single Layer Plastic Sheet Extruder Sheet PS Sheet Extrusion Line Machine

1 Set
MOQ
$150,000.00(>=1 Sets)
Price
Single Layer Plastic Sheet Extruder Sheet PS Sheet Extrusion Line Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Sheet, Profile
Plastic Processed: PE, PP, PET
Condition: New
Screw Design: Single-screw
Screw Material: 38CrMoALA
Screw Diameter (mm): 90 Mm
Screw L/D Ratio: 32:1
Screw Speed (rpm): 1480 Rpm
Showroom Location: None
Voltage: 380V 50HZ 3P, Or Customized
Dimension(L*W*H): 18*8*6 M
Power (kW): 650
Weight: 10T
Warranty: 1 Year
Key Selling Points: Automatic
Applicable Industries: Manufacturing Plant
Marketing Type: New Product 2020
Video Outgoing-inspection: Provided
Machinery Test Report: Provided
Warranty Of Core Components: 1 Year
Core Components: Motor, Pump, Gear, PLC, Gearbox, Screw
Name: Sheet Extrusion Line
OEM: Offer
T-Die: Die Head Width 1000~2100mm
Product Thickness: 0.6~4.0mm
Line Speed (max): 12m/min
Extruder HP: 90~375kW High Efficiency AC Three Phase Frequency Converter Motor
Power: 350kw
Forming Rollers: 300~500mm X 3 Sets
Product Width: 800 Mm ~ 3,000 Mm
Raw Material: PC, ABS, PS, PETG, APET, PP, PE
After-sales Service Provided: Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Japan, Malaysia, Morocco, Kenya, Argentina, South Korea, Chile, UA
Certification: CE
Basic Infomation
Certification: CE
Payment & Shipping Terms
Packaging Details: PS Sheet extrusion line plastic sheet extruder machine will be packed into plastic films and pallets.
Supply Ability: 20 Set/Sets per Year
Product Description
Products Description
General Overview of PS Sheet Extrusion Line
Item
Description
Materials
PET/PMMA/ABS/PC/PP/PS
Extruder
Twin screw extruders are available in φ58/58mm~φ92/92mm according to customer preference.
Single screw available in φ90mm~φ180mm
Productivity
200kg/hr ~ 800kg/hr
Extruder HP
190~375kW High efficiency AC three phase frequency converter motor
Line Speed (max)
12m/min
T-Die
Die head width 1000~2100mm
Product thickness 0.6~4.0mm
Forming Rollers
φ300~φ500mm x 3 Sets
Haul-off Equipment
1 Set
Annealing Oven
2~3 Sets
Corrugating Machine
Depends on pattern
Edge Trimmer
2 Sets
Waste Crusher
2 Sets
Cooling Equipment
1 Set
Micro-computer Cutting Unit
1set
Automatic Hydraulic Lifter
1set
Details Images
This machine is used to produce PP PE PLA PS plastic sheet rolls for thermoforming machine and vacuum forming machine, which is used for making disposable plastic water drinking cups, juice cups, tea cups, milk cups, ice cream cups, yogurt cups, jelly cups,bowls, food containers, lids, flowerpot, seeding trays, etc various packages.
ABS/PC/PP/PS Sheet Extrusion Line
Product Features
Futures of PS Sheet Extrusion Line
1.The whole line of the machine adopts Siemens PLC online control, which is convenient and simple to operate.
2.Single screw extruder and special screw are used to ensure the melting effect of plastic.
3.The hydraulic screen changer provides an excellent seal effect to ensure non-stop work.
4.The melt pump ensures the smooth extrusion of the plastic and the uniformity of the sheet.
5.Use high-precision molds to ensure the uniformity of extruded plastics.
6.Three-roll calendar provides good thermostat
7.The online trimming and recycling device avoids waste of side material, and can be recycled and crushed to the feeding hopper
online to realize real-time recycling and production.
8.The oven device ensures that the sheet does not curl.
9.The traction system is equipped with a meter counter to promptly remind the rewinding and changing reels.
10.Double-station automatic rewinding is adopted.
Product Application
PS sheet has the characteristics of high strength, high rigidity, easy processing and forming, and good heat-sealing performance. The packaging products processed by it are stable in shape and beautiful in appearance. It can be widely used for packaging in cosmetics, electronics, clothing and other industries.
BOPP bidirectional stretch film Non Woven Fabric Machine PP Melt Blown Fabric Machine
Why choose SUMINO MACHINERY?
1. Profession: SUMINO only make plastic extruder for more than 20 years, extensive experience and professional team ensure our leading position in plastic extruder industry.
2. Quality: The quality of products is footstone of enterprise's constant development, always endeavoring to do still better, quality comes first, developing & innovative is our responsibilities;
3. Delivery: We optimize factory management, and improve production flow so as to shorten production period for you in biggest extent;
4. Cost control: We do best to lower down production cost by our inner management improvement, so as to ensure that our products are competitive enough in market, and to realize higher performance-price ratio of our products.
FAQ
Q1: What is the guarantee of the machine? A1: The guarantee period of our machine is 12 months after the machine is installed well in buyer's factory;
Q2: What package do you use for the machine? A2: Painted the machine with anti-corrosion oil, and then covered with plastic film, and then packed into wooden case or fixed onto wooden pallet as per clients' requirements, or shall be loaded into container with film packing. After fixed all machines, we will use drying agent to keep container inside dry.
Q3: Do you have instruction manual to guide us if i buy the machine? A3: Yes, we supply detailed user manual for your reference. PLS read it carefully for guide. If there is still problem which could not be solved, PLS contact us, we are ready to help you anytime.
Q4: What is your service to overseas clients? A4: We supply perfect overseas service. We shall send engineers to overseas for machine installation and commissioning and test production guide, and also training to the workers of the buyer. And we are ready to give technical support anytime.
